Description
Features :
WiFi connection, no wiring work, no router forwarding settings.
Plug in and play, installation very easy and simple.
WiFi range up to 50 meters.
Dual antenna wifi NVR.
IP66 waterproof metal housing.
Support Day/Night.
Support motion detection.
Support mobile control.
Plug in and play, installation very easy and simple.
WiFi range up to 50 meters.
Dual antenna wifi NVR.
IP66 waterproof metal housing.
Support Day/Night.
Support motion detection.
Support mobile control.
Specification :
| Wireless NVR | ||
| video input | Network Video | 4CH |
| Network video input broadbank | 20Mbps | |
| video output | HDMI input | 1CH, resolution: 1024×768, 1366×768, 1440×900,1920x1080p |
| VGA output | 1CH, resolution: 1024×768, 1366×768, 1440×900,1920x1080p | |
| AV CODEC Specification | Video Resolution | 720P |
| synch-playback | 4CH | |
| Video Control | Video/Capture mode | Maual / Time / Motion / Alarm |
| Playback mode | Real time / Routine / Event | |
| Backup | USB backup | |
| Hard Disk | Type | 1*SATA interface |
| Max Capacity | 4 TB at most for each | |
| External Interface | Network Interface | one adaptable RJ45 10M/100M, one 2.4Ghz WIFI interface |
| USB Interface | USB 2.0 | |
| Network Control | Protocol | UPnP (play&plug)/SMTP (email survice)/PPPoE (dial-up) |
| DHCP (Automatically obtain an IP address) | ||
| Others | Power Supply | DC12V2A |
| Power Consumption (W) | ≤5W (Without HDD) | |
| Operate Temperature (°C) | -10℃ to +55℃ | |
| Working Humidity (%) RH | 10%~90% | |
| Weight (excluding HDD) | 0.73Kg | |
| Dimensions | 257*210*42mm | |
| IP Camera | ||
| Sensor | 1/4” Progressive CMSO Sensor | |
| Signal System | PAL/NTSC | |
| Resolution | 1280 x 720 | |
| Minimum illumination | Color: 0.1 Lux; B/W: 0.01 Lux | |
| Shutter | 1/25s to 1/25,000s | |
| Lens | 3.6mm | |
| OSD | Date Time & Title | |
| White Balance | Auto | |
| Day&Night | Auto / Color / BW | |
| 3D-DNR | Auto | |
| Mirror/Flip | On / Off | |
| Frame Specification | Three Streaming at the Same Time: | |
| H.264 1280×720@15fps or below | ||
| H.264 640×480@30fps or below | ||
| S/N | > 39.1 Db | |
| Interface | RJ45 / WIFI 802.11b/g/n | |
| General | Anti-thunder Level | Standard IEC61000-4-5 |
| Working Temperature/Humidity | -10℃ to +50℃ / 30% to 80% RH | |
| Working Temperature/Humidity | -20℃ to +60℃ / 20% to 90% RH | |
| Power Input | DC12V 1A | |
| Power consumption | ≤6W | |
| Level of Protection | IP66 | |
| Weight | 0.35kg | |
| Dimensions | 107x68x60mm | |
| Package | Package Dimension | 340x185x270mm |
| Package Weight | 3.25kg | |
Package includeds :
1 x ESCAM WNK404 4CH WiFi NVR
4 x 720P IP WIFI Camera
5 x Screw Bag
1 x Mouse
5 x Power Adapter (EU/US/AU/UK Plug for Optional)
1 x User Manual
4 x Waterproof Hat
1 x Network Cable
4 x 720P IP WIFI Camera
5 x Screw Bag
1 x Mouse
5 x Power Adapter (EU/US/AU/UK Plug for Optional)
1 x User Manual
4 x Waterproof Hat
1 x Network Cable
