Description
**Product will be sent new version from CN warehouse(only from CN warehouse).
Features:
1. Support Off-line print, with Fast heating AC heated & MKS-Gen L mainboard
2. 95% assembled, easy to assemble, with high performance
3. Bowden style Titan Extruder with E3D hotend
4. Large printing size 300 x 300 x 400mm
5. With high accuracy printing quality reach to 50 microns
6. High Transverse speed
7. With Full Aluminum Frame design, golden color frame for upgraded newest version. Very stable structure.
8. Compact and small size all-in-one Powerbox with LCD control panel
| Specifications | |
| Model No. | TEVO Tornado |
| Printing Size | 300*300*400mm |
| Frame material | Aluminium Extrusion |
| Heated Bed Sticker | Without(new version) |
| Color Print Speed | 80-200mm/s |
| Control mainboard | MKS-Gen L |
| Material diameter | 1.75mm |
| Nozzle diameter | 0.4mm(can be changed to 0.3/0.2mm) |
| Memory card offline print | SD card |
| Print speed | Max 150 mm/s |
| Supporting material | PLA, ABS, PETG, Wood, PVA and Flexible Filaments |
| Layer resolution | 50 microns |
| Layer Thickness | 0.05-0.4mm |
| Layers Software | Cura/Repetier-Host |
| Recommended extruder temperature | 210°C (the maximum can be set to 260°C) |
| Heating plate temperature | 60-110°C |
| Best ambient temperature | ≥25°C |
| Language | English |
| File format | STL/OBJ/G-Code |
| Software supporting | PROE, Solid-works, UG, 3d Max, Rhino 3D design |
| Printing Method | TF card/ On Line / Off Line |
| Interface | USB 2.0, USB 3.0 |
| XY-axis positioning accuracy | 0.012mm |
| Z-axis positioning accuracy | 0.004mm |
| Power requirements | 220V, 250W, 50Hz, 0.89A |
| Connection | TF card or USB |
| System support | Windows, Linux, M ac |
| certification | CE, FC, ROHS |
| Product weight | 14KG |
| Package weight | 18KG |
| Product size | 560X 600X620mm |
| Package size | 660X 560X 310mm |
Note:
*
It is default EU plug. It will be a delivery adapter from Cn warehouse.
* There is not heated bed sticker for new version.
It is default EU plug. It will be a delivery adapter from Cn warehouse.
* There is not heated bed sticker for new version.
Package Included:
1x TEVO Tornado 3D Printer Kit(
sent randomly about the new version and the old version
)
