Are you worried about choosing a multimeter as a gift?
For your elders who do some diy regularly.
For your friends who is a electrician or profession.
For your child who is a student or go to school soon.
Please continue to understand our product – MUSTOOL MT99!!! The highest appearance value smart multimeter until now and more functional Than MUSTOOL MT77!!!
Upgrade Functions as Follow( Updates(compare with MT77 ):
1. High EBTN LCD large screen design
2. The world’s fastest capacitance measurement speed
3. The resistance measurement range is 1Ω-10MΩ;
4. Maximum display value: 9999;
5. Automatic identification and capacitance measurement of diode on-off gear position;
Features:
1. Ultra-large EBTN LCD, 3-line display, can show 3 test results on the screen, such as voltage, frequency and analog bar
2. Ultra-thin body, portable hanging hole, comfortable operation and easy to carry
3. Unibody test leads design, one step to test, no need to plug and pull
4. Singe button to start smart identification function, no need to switch gear, say goodbye to cumbersome operation
5. Back flashlight design, no fear of dark environment
6. AC and DC voltage test
7. Resistance, continuity
8. Data hold, automatic power off
6. Frequency test
8. LIVE: neutral and live wire judgment (live wire check)
10.V~alert: dangerous voltage alarm (non-contact voltage detection)
11.TRUE RMS: True RMS
12. Automatically identify diode and continuity
13. Capacitance test
14. Fastest measurement speed,especially for testing Capacitance.
Specifications:
| DC Voltage | 600V/0.1V | ± ( 0.8%+3 ) | min input voltage:0.5V max input voltage:600V input impedance:10M |
|
| AC Voltage | 600V/0.1V | ± ( 1.2%+5 ) | min input voltage:1V max input voltage:600V input impedance:10M |
|
| Resistance | 1Ω-10MΩ | ( 1.2%+3 ) | Overload protection 250V AC/DC | |
| Capacitance | 1000uF/0.1uF | ( 3.5%+8 ) | Minimum measurement capacitance 0.5uF Overload protection 250V AC/DC |
|
| 6000uF/1uF | ( 4.5%+10 ) | |||
| Frequency | 10HZ-1000HZ | ( 2%+10 ) | RMS above ACV1V | |
| Maximum display value | 9999 | |||
| Automatic shutdown | √ | |||
| Flashlight | √ | |||
| Diode | less than 1.0V diode automatic identification | |||
| Buzzer | √ | |||
| NCV (Non-contact voltage detection) |
√ | |||
| live wire check | √ | |||
| Undervoltage warning | √ | |||
Package included:
1 x Smart Digital Multimeter
1 x Test Lead
1 x User Manual
