Description
Wattage:
-
800W 5 Blades
-
800W 6 Blades
-
800W 3 Blades
Voltage:
-
12V
-
24V
Specification: Free MPPT Controller
- Brand Name: JSRX ZXX
- Type: Wind Power Generator
- Mounting Base: With Mounting Base
- Certification: CE
- Shaft Material: Stainless steel
- Model Number: RX-800H3
- Certification: RoHS , CE, ISO9001:2000
- Application: Wind Solar Hybrid system
- Start up speed: 2m/s
Technical Data
|
Rated watt |
800W |
|
Rated voltage |
12/24V |
|
Start-up wind speed |
2.0m/s |
|
Rated wind speed |
13m/s |
|
Survival wind speed |
50m/s |
|
Weight |
9.5kg |
|
Blade quantity |
3/5/6 pieces |
|
Blade lengths |
3 blades: 600mm 5 blades: 550mm 6 blades: 530mm |
|
Blade material |
Nylon fiber |
|
Generator |
Permanent magnet synchronous generator with three-phase alternating current |
|
Controller system |
Electromagnetic/yaw |
|
Regulating way |
Automatic adjustment of wind angle |
|
Working temperature |
-40°C~80°C |
