Description
Features:
– High current, high voltage withstand capability
– Good impact resistance
– Lower contact resistance
– Innovative sealing, waterproof and dustproof design, reaching IP67
– can adapt to different specifications of cable, customer-defined length; can be equipped with different models of connectors (compatible with MC4).
– Excellent high and low temperature, waterproof, UV resistance, etc., suitable for long-term outdoor use
Specifications:
● Wire Thickness: 10 AWG
● Stranding: 10
● Cable current requirements ambient temperature: 60°C
● Conductor maximum working temperature: 120°C
● Rated voltage: 1000V DC
● Rated current: 30A
● Cable specification: 4 mm2
● Number of shares of the cable: 56/0.3TS
●Outside diameter of cable: 6.10mm
● Waterproof and dustproof rating: IP67
●Insulation Thickness: 0.075 inches
●Nominal Outer Diameter: 0.28 inches
●Approximate Net Weight : 17.54 ft/lbs
●Ampacity 90ºC Wet/Dry: 40A
●Conductors: Fully annealed stranded bare copper per ASTM B3. Class B Stranding
●Insulation Jacket: Chemically crosslinked polyethylene
● Ambient temperature: -40°C to +85°C
Package Included:
1 x Black & Red Color Solar Panel Extension Cable Wire
![1M AWG10 Black or Red MC4 Connector Solar Panel Extension Cable Wire 1M AWG10 Black or Red MC4 Connector Solar Panel Extension Cable Wire 11](https://img.staticbg.com/images/oaupload/banggood/images/25/C2/480b8071-5167-42cb-bd3c-8c655d7b5099.jpg)
![1M AWG10 Black or Red MC4 Connector Solar Panel Extension Cable Wire 1M AWG10 Black or Red MC4 Connector Solar Panel Extension Cable Wire 12](https://img.staticbg.com/images/oaupload/banggood/images/97/06/76e5be02-c5c3-45ff-8af8-f748ab77658e.jpg)
![1M AWG10 Black or Red MC4 Connector Solar Panel Extension Cable Wire 1M AWG10 Black or Red MC4 Connector Solar Panel Extension Cable Wire 13](https://img.staticbg.com/images/oaupload/banggood/images/18/BD/28d6b9f1-8375-4a55-86bf-9ed5dae4cfbe.jpg)
![1M AWG10 Black or Red MC4 Connector Solar Panel Extension Cable Wire 1M AWG10 Black or Red MC4 Connector Solar Panel Extension Cable Wire 16](https://img.staticbg.com/images/oaupload/banggood/images/28/D5/4f3670c3-47d5-4f52-a552-293788f6eb3d.jpg)
