Description

OVERVIEW

The Seasonic PRIME Platinum 850 watt power supply is a champion is stable and reliable power delivery. It boasts a near-perfect voltage output which represents Seasonic’s market leading engineering feat. This unit is ideal for users who want o reduces noise levels in their work environment, as it has an oversized, 135 mm Fluid Dynamic Bearing Fan that is controlled by Seasonic’s proprietary Premium Hybrid Fan Control. An innovative Cable-free Connection Design solution employs highly conductive copper plate to replace the traditionally used cables for a cleaner design an to increase power efficiency.

SPECIFICATIONS

• 80PLUS: Platinum
• Form Factor: Intel ATX 12 V
• Dimensions: 150 mm (W) x 170 mm (L) x 86 mm (H)
• Fan Size: 135 mm
• Fan Control: Premium Hybrid Fan Control
• Fan Bearing: Fluid Dynamic Bearing
• Life Expectancy: 50,000 hours at 40 °C, 15 % – 65 % RH
• Modularity: Fully Modular
• Cable type:
• Motherboard, CPU, PCIe – Black webbeb cables
• SATA, Molex, Floppy – Flat black cables
• Operating Temperature: 0 – 50 °C
• MTBF @ 25 °C, excl. fan: 150,000 hours
• AC Input: Full Range
• Protection: OPP, OVP, UVP, OCP, OTP, SCP
• Safety and EMC: cTUVus, TUV, CB, CCC, BSMI, EAC
• Environmental Compliance: Energy Star, RoHS, WEEE, ErP Lot 6, REACH
