LCD screen display all parameters.With output switch, intelligent control, easy to operate. Fully automatic operation.Microcontroller digital accuracy.A key to open and close the load.PWM charging modeWith separated temperature detected circuit, high precision temperature compensation function.





Color: BlackMaterial: PlasticVoltage of Battery: 12V / 24V AutomaticRated Charge/Discharge Current: 20AUSB Output Voltage: 5VTotal USB Output Current: 3AOverload/Short Circuit Protection: 1.5 Times by Rated CurrentShort Circuit Recovery Time: 10sFloat Charge Voltage: 13.7V; x2/24VDischarge reconnect Voltage: 12.6V; x2/24VDischarge stop Voltage: 10.7V; x2/24VControl Mode: PWMWorking Temperature: -35~60°C





1 x Solar Charge Controller1 x User Manual



,,,,,,,,,
